HMH-52DE
SATA Revision 3.2
-
It can reach up to 550MB/s read and 500MB/s write high performance standard, with low power consumption compared to traditional hard drive, which making it the ideal storage device for embedded solution.
Download Files
Product Specifications
| Series Name | HMH-52DE | ||||
|---|---|---|---|---|---|
| Interface | SATA Revision 3.2 | ||||
| Capacity Coverage | 16GB up to 1TB | ||||
| Capacity | |||||
| 3D TLC | 64GB up to 1TB | ||||
| 3D pSLC | 16GB up to 256GB | ||||
| Performance Overview | Seq. R : 550 MB/s ; Seq. W : 500 MB/s | ||||
| Performance | |||||
| 3D TLC | Seq. R : 550 MB/s ; Seq. W : 500 MB/s | ||||
| 3D pSLC | Seq. R : 550 MB/s ; Seq. W : 510 MB/s | ||||
| Standard Operating Temperature | 0°C ~ 70°C | ||||
| Extended Operating Temperature | -25°C ~ 85°C | ||||
| Dimension LxWxH (mm) | 26.8mm(L) x 29.85mm(W) x 3.7mm(H) | ||||
| Technology | ##S.M.A.R.T | ||||
| Data Sheet |  |
||||
